Markoprint X4JET plus Touch
X4JET plus Touch
Ultra-fast, Standalone Print Controller for 4 Printheads
The Markoprint X4JET plus Touch is a 5.7″ high-resolution TFT color touchscreen display and controller. This unit controls a wide array of printheads and head configurations that can adapt to almost any application.
The X4JET is used to communicate to a printhead that does not have its own intelligence as well as visualize print jobs and statuses of certain Markoprint printheads that do not have a built-in display. The animated graphics provide user friendly control. Four different print technologies are supported, HP, LX, MX, and XR. Mix print technologies. Run up to 4 separate supported print technologies simultaneously with the X4JET.
The X4JET can operate up to 4 printheads simultaneously, giving you the options to print on two different sides of a package, two different production lines, as well as the ability to stack printheads to get a larger print height. Height varies based on the print technology.
The touch screen as well as full keyboard enables you to create print messages directly from the X4JET Controller. At a glance you can see whether the printing system is active as well as check the print speed & cartridge ink levels. You can also start & stop, delay, change intensity, set passwords, and adjust encoder signals right from the X4JET.
The touch screen responds to thin work gloves, bare hands and stylus pens.
Seamlessly Integrate With Systems Such As:
Vertical and horizontal band sealers, thermo-forming, conveyor belts, bottling and filling lines, labeling equipment, stretch wrap machines, shrink wrap machines, side & bottom seal, sachet machines, flexible pouch, form, fill, & seal equipment, as well as almost any material handling options on the market today.
Coding needs may vary based on application, customer, substrate, & regulations but consistency and quality are paramount across the board when looking for a marking and coding system and team to trust.
As configurations and accessories vary depending on environment, application, and/or customer specifications, our sales team will work with you to ensure you’re purchasing the best solution for your project(s).
Technical Features
- Print with True Type fonts
- Alphanumeric Text
- 1D & 2D Barcodes
- Graphics & logos
- Compact design
- Print from the side or top down
- Supports four different print technologies. HP, LX, MX, XR
- Mix print technologies. Run up to 4 separate supported print technologies simultaneously with the X4JET
- 4 printheads up to 284mm (11.2”)
- Data transmission initialized with USB stick, ethernet, PLC or web interface
- Encoders for different belt speeds or system downtimes
- Flex holder for different product distances
- 5.7” touch screen TFT
- Mounting brackets for horizontal and vertical applications
- Max Print height from 50mm to 400mm depending on the print technology
- HP & LX :
- 1 printhead up to 12.5mm (½”) print height
- 2 printheads up to 25mm (1”) print height
- 3 printheads up to 37.5mm (1.5”) print height
- 4 printheads up to 50mm (2”) print height
- MX:
- Available with a 50mm or 100mm printhead. Up to 200mm-400mm print height possible.
- XR:
- 1 Printhead up to 71mm (2.8”)
- 2 printheads up to 142mm (5.5”)
- 3 printheads up to 213mm (8.4”)
- HP & LX :
- Parallel operation using a standard keypad and function keys
- Networking possibilities using TCP/IP, USB and EIA232
- Print on up to two production lines
- Simultaneous marking of primary and secondary packaging using a single controller
- New printhead for every new cartridge (with HP & LX technologies)
- Absorbent & non absorbent surfaces (depending on print technology)
- Robust industrial printer
- High resolution (600 dpi)
- Print Speeds at 300dpi optimum intensity:
- Up to 60m/min with MX
- Up to 67/min with XR
- Up to 180m/min with HP
- Up to 240m/min with LX
Common Industries and substrates for the X4JET plus Touch
The X4JET paired with AMI’s multitude of printhead options offers solutions for a broad range of packaging colors & materials that will adapt to your products. Designed to accommodate industries such as food, protein plants, beverage, medical device, pharmaceutical, chemical, lumber, cannabis & hemp, etc. Click through below or look through our industry pages to see the full details on your desired industries.
This unit provides easy solutions for SARA III as well as track and trace requirements. Connect to conveyors, cartoners, vertical and horizontal baggers, sealers, form fill and seal machines, as well as any other new or existing lines with ease! Compatible with UDI (Unique Device Identifier) as well as track and trace initiatives. Selecting the right technology to print vital identification information is crucial. Print lot, exp, serialization, date codes, barcodes, ANSI Grace A GS1 compliant barcodes, and any other required alphanumeric text and graphics. Print directly onto your hard to print on surfaces – glass, plastic, metal, etc.
